Brand Name : TOPFENCE®
Model Number : Temporary Fencing panels
Certification : AS4687-2007
Place of Origin : China
MOQ : 250 kit included temporary fencing panel ,block and clamp system
Price : 12.88USD -38.88USD
Payment Terms : T/T, Western Union, MoneyGram, Western Union
Supply Ability : 5000 pcs per week
Delivery Time : 15 days
Packaging Details : metal pallet wrapped with plastic bubble
Color : Silver
Materials : Q195 and Q235
Panel size : 2100mm x 2400mm
Mesh : Opening 60mm x 150mm
1.Material: Pipe(42 Microns) and HDG Wire(28 Microns)
2.Panel Size(HxL):2100x2400mm, 1800x2400mm, 1800x2500mm,
2100x2900mm, 2100x3300mm
3.Wire dia :3.5mm,4.0mm,4.5mm,5.0mm (Normal 4.00mm)
4.Frame Pipe: 32mm O.D, 38mm O.D, 42mm O.D, 48mm O.D(2.0MM Thick)
5.Mesh Size: 50 x 150mm, 75x150mm, 60 x 150mm etc.
6.Surface treatment : Hot dipped galvanized,Hot dipped galvanised(42microns)
7.Characteristics : UV resistance,Weather resistance,easily install ,durable,beautiful appearance , bright comfort feeling , wiew widely .
8.Application : construction sites,crowd control barriers,swimming pool,security sites, residential housing sites, major public Events, sports, concerts, festivals, gatherings etc.
9. Delivery Time: With 25Days and 540pcs in 40HC Container.
Material: High quality mild steel wire
•Type:Welded mesh
•MOQ:10 sets
•Surface Treatment: Electric galvanized or Hot dip galvanized, PVC coated
•Technique: Welded
•Usage: Used for garden,road,playground,park etc
•Packaging Details:
Packed with plastic film then on the pallets and then in wooden box
•Delivery Detail:10-15 days after received
your deposit
Blow molding Base Version HDPE materials |
Suit Pipes |
|||||
Size |
600 x 228 x 150mm |
Size |
620 x 230 x 130mm |
Size |
600 x 228mm x 150mm |
OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm |
Materials |
HDPE |
Materials |
HDPE |
Materials |
HDPE |
|
Finish |
UV 3 -UV5 |
Finish |
UV3-UV5 |
Finish |
UV3-UV5 |
|
Colors |
Orange, Green ,Yellow etc |
Colors |
Orange, Green ,Yellow etc |
Colors |
Orange ,Green ,Yellow etc |
|
Weight |
After filled 27kg-29kg |
Weight |
After filled 27kg-28kg |
Weight |
29kg |
|
Design |
Australia |
Design |
Australia |
Design |
Australia |
|
Clamp |
100mm center to center |
Clamp |
90mm center to center |
Clamp |
80mm |
|
|
|
|
Blow molding Base Version HDPE materials |
Suits pipes |
|||||
Size |
615mm x 230mm x 100mm |
Size |
620 x 230 x 130mm |
Size |
600 x 220mm x 150mm |
OD 32mm |
Materials |
HDPE |
Materials |
HDPE |
Materials |
HDPE |
|
Finish |
UV 3 -UV5 |
Finish |
UV3-UV5 |
Finish |
UV3-UV5 |
|
Colors |
Orange, Green ,Yellow etc |
Colors |
Orange, Green ,Yellow etc |
Colors |
Orange ,Green ,Yellow etc |
|
Weight |
After filled 27kg |
Weight |
After filled 27kg-28kg |
Weight |
29kg |
|
Design |
Australia |
Design |
Australia |
Design |
Australia |
|
Clamp |
100mm center to center |
Clamp |
100mm center to center |
Clamp |
100mm |
|
|
|
|
|
Temporary Fencing Block -Blow Molding fill Water |
Suit pipes |
|
Materials |
High density poly-ethylene (HDPE) |
|
|
Color |
Green ,Yellow ,Black |
||
Weight |
26kg after filled warer |
||
Packing |
Stacking together as pallet |
||
Treatment |
UV 3 ,UV 4 UV 5 |
||
Size of foot |
600 x 220 x130mm |
||
Packing |
Metal pallet |
|
Temporary Fencing Block --Recycled Rubber Foot |
Suit pipes |
|
Materials |
Recycled rubber foot |
|
|
Color |
Green ,Yellow ,Black |
||
Weight |
19KG |
||
Packing |
Stacking together as pallet |
||
Treatment |
Oil painted |
||
Size of foot |
767 x 192 x 126mm |
||
Packing |
Metal pallet |
|
Temporary Fencing Block - Injection Molding foot |
Suit pipes |
|
Materials |
High density poly-ethylene (HDPE) |
OD 32mm OD 38mm OD 40mm OD 42mm OD 48mm |
|
Color |
Green ,Yellow ,Black |
||
Weight |
30kg |
||
Packing |
Stacking together as pallet |
||
Treatment |
UV 3 ,UV 4 UV 5 |
||
Size of foot |
560 x 245 x 130mm |
||
Packing |
Metal pallet |
![]() |
Temporary Fencing panels Supplies,2100MM*2400MM width standard AS4687 fence panels Images |
